| 產地 |
深圳
|
是否進口 |
否
|
訂貨號 |
KW901
|
| 加工定制 |
是
|
貨號 |
KW901
|
類型 |
汽車故障診斷儀
|
| 電壓 |
12（V）
|
工作溫度 |
常溫（℃）
|
品牌 |
KONNWEI
|
| 型號 |
KW901
|
適用車型 |
多款汽車
|
主要下游平臺 |
wish,亞馬遜,速賣通,獨立站,LAZADA,e
|
備注：本產品只可以檢測12V的符合OBD2,EOBD標準，是這五大協議：CAN , J1850 PWM , J1850 VPW, ISO9141, KWP2000 中的一個協議的汽油車/柴油車/混合動力車?？蛻粝螺d安裝什么語言的軟件就會顯示什么語言，默認英文。
本品牌所有產品在亞馬遜銷售賣家要建立自己的鏈接，自己推廣。不可以在亞馬遜跟賣其他賣家的Listing，發現就馬上投訴以及做Test Buy處理，后果自負。
Features:
*Supply voltage(VDD):12V
*Work temperature range: -20 ~ +70℃
*Storage temperature range:-40 ~ +125℃
*RF sensitivity(Basic Rate): -85db
*Modulation Mode:GFSK
* Frequency Range:2402 ~ 2480MHZ
* Transmission Range:10M
* Bluetooth Profile:SPP
* UART Params:38400,8,n,1
* Small size, compact structure. Plug and never unplug
* Stable wireless connection
* No wires or batteries (adapter is powered by the diagnosis size sockets)
* Stop communication, wait half an hour, auto sleep
* Supports all OBDII protocols
* The adapter uses the fastest and most reliable ARM chips
The device is a small adapter that plugged into the vehicle OBD-connector.
On Bluetooth, it connects to any computer, tablet or smartphone, With
associated diagnostic procedures . Doing these simple operations, you will be
able:
* Measure the fuel consumption.
* Display real-time operating performance of the car, such as momentum,
vehicle speed, oil pressure, coolant temperature, engine load, intake manifold
pressure, throttle position, the values of oxygen sensors, air intake
temperature, and more.
* Turn off the MIL (signal Check Engine).
* Download data to external media in a variety of formats for later printing.
* Record various parameters, display graphics in real time, and more.
With kw901 you will be able to perform a complete computer diagnostics car
and even to correct minor faults without resorting to service stations.
kw901 scantool is a high-quality automotive scanning tool, supports all OBD-II
protocols :
0.Automatic
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)
