點擊圖片查看原圖
| 產地 |
廣東深圳
|
是否進口 |
否
|
訂貨號 |
V310
|
| 加工定制 |
否
|
貨號 |
V310
|
類型 |
汽車故障診斷儀
|
| 電壓 |
9-16（V）
|
工作溫度 |
-20到70（℃）
|
型號 |
V310
|
| 適用車型 |
兼容9個協議的車都適用
|
包裝方式 |
吸塑包裝
|
包裝尺寸 |
258 X 175 X 62mm
|
1. Product parameters：
Display: Backlit, 128 * 64 pixel display
Working temperature: 0~60℃(32~140℉) S
Storage temperature: -20~70℃(-4~158℉)
External power supply: Vehicle batteries supply 8.0 to 15.0V
Size: Length: 155mm, width: 85mm, height: 25mm
Weight: 0.198Kg (0.431b)
2. Product Features：
2. Read error and Clear diagnostic code---general and factory specified and display their meanin
2.2 Easily determines the cause of the check engine light
2.3 View freeze frame Information
2.4 Displays I/M readiness Status
2.5 Retrieves vehicle information
2.6 Data stream
2.7 Real time curve
2.8. Retrieves car speed information
2.9. DTC one click que
2.10. Support Multi Languages: English, French, Spanish, Deutsche ,Dutch
3. Protocol Support：
1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2 (5 baud init, 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
5. ISO14230-4 KWP (fast init, 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID, 500 Kbaud)
7. ISO15765-4 CAN (29bit ID, 500 Kbaud)
8. ISO15765-4 CAN (11bit ID, 250 Kbaud)
9. ISO15765-4 CAN (29bit ID, 250 Kbaud)
. Warranty
Certified CE, FCC, RoHS compliant
Warranty: 1 year
